Contact Type Plain Ring Gauge
Repeatability: < 1 micron
Application Range: 4 mm to 125 mm for OD
The contact type plain ring gauge is available in a variety of materials and radii, depending on the material and the roughness of the diameter to be measured. Only one master is required for zero setting, and it is compatible with electronic units featuring LVDT or HBT transducers. Users can customize the measurement depth between 1 mm and 6 mm.
Key Benefits:
- High precision with a measurement deviation of 0.002mm and repeatability of 0.0005mm.
- Easy to use and handle, ensuring a high level of productivity and repeatability.
- Compatible with all major brands of digital electronic or dial indicator gauges.
- The measuring sleeve design eliminates the need for tilting when entering the bore.
- Cross sleeve designs reduce weight and improve handling for inspecting large diameters.
